Product Features
- Single-sided or double-sided printing module
- Over the edge printing
- Color dye sublimation, Resin monochrome retransfer
- 600 dpi print head (23.6 dots/mm)
- Flash Memory 4 GB – RAM 256 MB
- Lifetime warranty on the print head
- 3-year warranty on the rest of the printer
Print Technology
- Color dye sublimation and Resin monochrome retransfer
- Print Speed: Single side 150 cards/hour with YMCK / Dual side 100 cards/hour with YMCKK
- Input Hopper capacity: 200 cards
- Output Hopper capacity: 100 cards
- Reject hopper capacity: 10 cards
- Connectivity: Ethernet TCP-IP 10BaseT, 100BaseT, USB 2.0
Options
- Electromechanical locking system
- Digital Erasing
- UV printing through YMCFK and driver implementation
- Data encryption for magnetic encoding
- Option to apply two layers of retransfer film
Encoding modules
- Magnetic stripe encoder ISO 7811 / JIS Type II
- Smart contact station ISO 7813
- Smart encoding unit
- Contactless encoding unit
- Internal USB or IP ports
Card Management and Specification
- Feeder capacity: 200 cards (0.76 mm – 30 mil)
- Output hopper capacity: 100 cards (0.76 mm – 30 mil)
- Reject tray capacity: 10 cards (0.76 mm – 30 mil)
- Card thickness: 0.76 mm to 1.25 mm (30 – 50 mil)
Types of Compatible Cards
- PVC cards
- Composite PVC cards
- PET cards
- ABS cards
- PC cards
- Card format: ISO CR80 – ISO 7810
- 85,6 x 53,98 mm (3.370″ x 2.125″)
