Product Features
- Supports wide range of identifiers: Access using EM-Marin, MIFARE, NFC, and Bluetooth.
- Multi-language web interface: Enables easy configuration and management.
- Wide operating conditions: Operates between –40°C to +65°C with IP65 protection rating.
Specifications
| Category | Specification |
| Device Type | Standalone / Network reader with controller |
| Protection Class | IP65 |
| Working Temperature | -40 — +65 °C |
| Power Consumption | 6.5 W, in standby — 2.5 W |
| Power Supply | PoE, +12 V DC (+12% -6%) |
| Case | Metal with glass faceplate |
| Colours | Black, Gold, Silver |
| Dimensions | 99 × 159 × 48 mm |
| Installation | Flush mounting, wall mounting with BR-AV2 |
| IK-Code | IK07 |
| Box Dimensions | 224 × 131.5 × 110 mm |
| Gross Weight | 1.20 kg |
| Interface | Multi-language WEB-interface |
| Lock Opening | Access card, BAS-IP UKEY application, API |
| Access Control | UKEY (EM-Marin / MIFARE® / NFC / Bluetooth) |
| Integration with ACS | Wiegand output (26, 32, 34, 37, 40, 42, 56, 58, 64 bit) |
| Supported Wiegand Types | 26, 32, 34, 37, 40, 42, 56, 58, 64 bit |
| Controller Capacity | Up to 20,000 identifiers with multiformat UKEY reader |
| Shortcut Buttons | No |
| Authentication | Separate password for settings via WEB-interface |
| Additional Features | Software Link support, SIP P2P, Built-in relay, Open API |
| Supported Identifier Types | EM-Marin (EM4100) [ASK 125 kHz], MIFARE Ultralight, Ultralight C, Ultralight EV1, Classic 1K/4K, Classic EV1 1K/4K, ID, Mini, Plus 2K/4K (ISO 14443 Type A 13.56 MHz), BLE (Bluetooth Low Energy 2.4 GHz), Temic (FSK 125 kHz) |
