Specifications
| Category | Specification |
| Interface to BAS-IP Panels | RS485 (A & B) |
| Power Supply | +12 V DC (Powered by BAS-IP panels) |
| Current Consumption | 0.15 A |
| Interface for External Readers | Wiegand 26, 34, 58, 64, 66 bit |
| Interface for Access Controllers | Wiegand 26, 34, 58, 64, 66 bit |
| Operating Temperature | -40 – +70°C |
| Storage Temperature | -15 – +65°C |
| Permissible Humidity | 20 – 80% |
| Degree of Protection | IP30C |
| Weight | 0.11 kg |
| Dimensions (Without Mounting Brackets) | 82 × 56 × 34 mm |
| Dimensions (With Mounting Brackets) | 115 × 56 × 34 mm |
| Additional Features | Power output for external readers (+12 V DC), Alternative power output for external readers (+5 V DC), Activity and data transmission intensity indicator LED |
