| Category |
Specification |
| Panel Type |
Multi-button |
| Induction Loop |
Yes |
| Status Indicator |
3 indicators (Calling, Talking, Lock-release) |
| Resolution |
2.0 MP |
| Camera Angle |
110° (horizontal) |
| Output Video |
HD (1280 × 720), H.264 Main Profile |
| Night Backlight |
6 LEDs |
| Light Sensitivity |
0.01 Lux |
| IK-Code |
IK08 |
| Protection Class |
IP65 |
| Working Temperature |
-40 – +65 °C |
| Operating Humidity |
0% – 86% |
| Storage Humidity |
0% – 60% |
| Power Consumption |
6.5 W, in standby – 3.6 W |
| Power Supply |
+12 V DC (+8% -4%) |
| Case |
Aluminium |
| Colours |
Gold, Silver, Black |
| Dimensions |
379 × 158 × 49 mm |
| Installation |
Flush mounting, wall mounting with BR-AA12 |
| Keyboard |
Mechanical buttons with backlight |
| Box Dimensions |
440 × 202.5 × 97 mm |
| Gross Weight |
3.42 kg |
| Interface |
Multilanguage, WEB-interface |
| Lock Opening |
Monitor, Face Recognition, QR code, Guest link, PIN, Access card, License plates, BAS-IP Link app, BAS-IP Intercom app, BAS-IP UKEY app, API |
| Access Control |
Face Recognition, UKEY (EM-Marin / MIFARE® / NFC / Bluetooth), Multi-factor authentication |
| Supported Standards |
BLE 2.45 GHz (Bluetooth 4.x / 5.x), Mifare® 13.56 MHz ISO14443A, NFC 13.56 MHz ISO14443/15693, 125 kHz cards (ASK and FSK) |
| Reading Range |
NFC/Mifare/125 kHz: up to 5 cm; BLE: adjustable 10 cm – 10 m |
| Lift Calling |
Yes |
| Face Recognition Identifiers |
10,000 faces |
| Panel Memory Identifiers |
20,000 (QR codes, cards, key fobs, UKEY, access codes) |
| ONVIF (Profile S) |
Yes |
| ACS Integration |
Wiegand (26–80 bits) |
| External Induction Loop Output |
Low-frequency audio signal 1.2V; 8.2 kOhm, Socket (female) TRS |
| Additional SH-12 Module Support |
Wiegand input 6–58 bits; Wiegand output 26–128 bits |
| Quick-Dial Buttons |
Concierge call button |
| Number of Ringtones |
4 polyphonic ringtones |
| Authentication |
Separate password for settings, WEB-interface |
| Additional Features |
Software Link support, SIP P2P, Built-in relay, Open API |
