Key features
- All-in-one RFID solution for retail: You get access to an RFID reader, antenna, and computer – all in one package. External hardware is not required, thanks to the integrated antenna and edge computing.
- The Sampo line has delivered over eight years of unparalleled quality and uncompromising performance
- It’s easy to mount and install due to its lightweight, slim, unobtrusive design and integrated mounting brackets.
- Sampo S3 can be powered through an Ethernet cable.
Specifications
You can find key specifications of Sampo S3 in the table given below:
| Supported standard
Frequency band Regulatory |
ISO 18000-63 (EPC Class 1 Gen2v2)
ETSI 865.6-867.6 MHz and FCC/IC 902-928 MHz |
| Integrated antenna features | Wide band antenna which covers ETSI and FCC/
IC frequency band, 7dBIc circular polarized, Beam width 80° |
| Radiated power (integrated antenna) | Maximum: 33 dBm (2W) ERP / 3.3 W EIRP
Minimum: 4 dBm (2.5mW) / 4 mW EIRP |
| Memory | 1GB RAM 8GB Flash |
| CPU | Quad-core A7 1.1GHz |
| Indicators | 4 pcs LEDs: Connection, Error/status, Power, RF Buzzer for sound indications |
| USB | USB host, type A USB device, type C (CDC serial port and HID profiles supported) |
| Bluetooth | BT 2.1 + EDR/3.0/4.1 LE /BT4.2 |
| Software | Ready-to-use Nordic ID NUR API that provides full control over the reader. Application can be written with modern programming languages. MQTT support (broker or client). Compatible with existing Nordic ID fixed readers. |
| Security | TLS v1.3, WLAN profiles: WPA2-Personel and WPA2- Enterprise (PEAP-MSCHAPV2 and EAP-TTLS/PAP) |
